Description
Aurora series inward open walk-in tub, size 51L x 29.5W x 42H in
- 22.5″ seat
- Widened 17¾” opening door
- Hand-held shower with 5 foot hose attached and a stylish faucet are included
- Extra safe, easy to operate lock that does not trouble your movement while bathing
- Safety grab bars
- Optional Tub Surround Available
- Available with 16 heated air jets
- Available with whirlpool system and built-in inline heater
- Molded seat – 17” high meeting ADA’s minimum height requirement
- Waterproof inward swinging walk-in door
- Easy to remove front access panels
- 2 inch drain system for quicker draining time
- Left and right hand drains available
- Limited life time warranty on the door seal
- 29.5 inch outside dimension
- 8 inch filler/extension panel available
- UPC CERTIFIED WATER MANIFOLD (5 YEAR WARRANTY)
- Easy installation (4-6 hrs)
- Tub can be free standing/movable or built in
- Convenient / easy to reach controls
- 4-5 foot flexible metal supply hoses for easy water connections
- 50-60 gallons
- High quality ABS composite /acrylic with fiber glass backing
- Self leveling feet for quick and sure leveling
- ¾ in entry pipe filler provides double speed tub filling
- Overflow protected
- Textured tub floor
- Upgrade panels available
- All tubs have adjustable height + or – an inch
Lowes Model Number: HY23, NE2331, NE2331L, NE2331R, NE2311L, NE2311R, NE2321L, NE2321R, NE2321, NE2311, HY-1123, HY1223, HY1323
*The Company shall bear no responsibility whatsoever for any act or failure to act by any entities installing and/or delivering the Company’s products to its customers.
Available in five versions:
- HY1323-Soaker Tub
- HY1323P-Soaker tub with Heated Shell
- HY1223A-Soaker tub with Air Jets
- HY1123W-Soaker tub with Water Jets
- HY1123WA-Soaker tub with Water & Air Jets
- Easy 4-6 hours Installation
- Front access panel
- High volume tub filler
- 8" Extension Panel ( optional extra)
- Limited Life Time Warranty on the door seal
- 17" High Molded Seat
- Meets ADA's minimum height equirements
- 2" Drain
- Waterproof inward opening door
- Safety grab bar
- Hand held shower
- Drain access panel
- Left/Right Models Available
- Factory tested
PLUMBING REQUIRMENTS
- Unit is equipped with flexible, metal braided ¾ inch water supply hose with ¾ inch female threaded connectors
- It is needed to install hot and cold shutoffs with ½ inch male threaded nipples (not included)
- It is advised to have tub onsite before preparing drain location
Note:The flexible drain hose that is included with this unit is for installation into a floor drain only.
Substituting the existing drain show for a different one will not void the warranty as long as there is no
damage or evidence of misuse.
ELECTRICAL INFORMATION
- Air jet motor with heater: Dedicated 12-2 wire with 110 volt, 10-15 amp GFCI breaker
- Whirlpool System with heater: Dedicated 12-2 wire with 110 volt, 15-20 amp GFCI breaker
Technical Data:
| Materials | ABS Composite Acrylic |
| Size | 51 x 29.5 x 42 |
